Description
The Deye SUN-12K-SG05LP3-EU-SM2 is a 12kW three-phase low-voltage hybrid inverter from the SG05LP3-EU-SM2 series (3-12kW), designed for larger residential and light commercial solar and battery systems in South Africa.
- IP65 protection, suitable for indoor and outdoor installation
- Rated AC output: 12000W | Max AC apparent power: 13200VA
- Battery voltage range: 40-60V (lead-acid or lithium-ion) with self-adaptation to BMS
- 48V low voltage battery with transformer isolation design
- Max charging/discharging current: 240A
- Max PV access power: 24000W | Max PV input power: 19200W
- Dual MPPT (2/2+2), max operating PV current 26A+26A
- Max PV input voltage: 800V | MPPT range: 200-650V
- Peak power (off-grid): 2x rated for 10 seconds
- Max continuous AC passthrough: 45A
- 100% unbalanced output, max output up to 50% rated power per phase
- Supports up to 10 units in parallel (on-grid & off-grid) and multiple batteries in parallel
- AC couple for retrofitting existing systems
- Generator support for energy storage
- 6 programmable time periods for charge/discharge
- Max efficiency: 97.6% | Euro efficiency: 97.0% | MPPT efficiency >99%
- Intelligent air cooling, noise ≤55dB
- NRS 097 compliant
- Rated AC input/output current: 18.2/17.4A | Max AC input/output current: 20/19.2A
- Operating temperature range: -40 to +60°C (derating above 45°C)
- Monitoring (optional): GPRS/WiFi/Bluetooth/4G/LAN
- Warranty: 5 Years/10 Years (the warranty period depends on the final installation site of the inverter; refer to the Deye warranty policy)
Official Datasheet: Deye SUN-(3-12)K-SG05LP3-EU-SM2 Datasheet
Official Product Page: Deye SG05LP3-EU-SM2 (3-12kW) Series
This product must be installed by a qualified electrician. All installations must adhere to local wiring regulations and standards.
