| Maximum power (Pmax, STC) |
625W |
| Open circuit voltage (Voc) |
49.22V |
| Short circuit current (Isc) |
16.14A |
| Voltage at maximum power (Vmp) |
40.48V |
| Current at maximum power (Imp) |
15.44A |
| Module efficiency |
23.14% |
| Power output tolerance |
0 to +3% |
| Rear-side power gain (615W baseline) |
646W at 5% | 677W at 10% | 707W at 15% | 738W at 20% | 769W at 25% |
| Bifaciality |
70 ±5% |
| Temperature coefficients |
Pmax -0.280%/°C | Voc -0.230%/°C | Isc +0.050%/°C |
| Nominal operating cell temperature |
45 ±2°C |
| Operating temperature |
-40°C to +85°C |
| Maximum system voltage |
1500V DC (IEC) |
| Maximum series fuse rating |
35A |
| Protection class | fire rating |
Class II | IEC Class C |
| Cells |
132 (6 x 22), BC cell |
| Glass |
Dual glass, 2.0 + 2.0mm semi-tempered |
| Frame |
Anodised aluminium alloy |
| Junction box |
IP68, three diodes |
| Output cable |
4mm², +400 / -200mm or ±1400mm (length can be customised) |
| Mechanical load |
Front 5400Pa | rear 2400Pa |
| Hail test |
25mm hailstone at 23m/s |
| Dimensions |
2382 x 1134 x 30mm |
| Weight |
33.5kg |
| Packaging |
36 pcs per pallet |
| Certifications |
IEC 61215, IEC 61730, IEC 62941, ISO 9001, ISO 14001, ISO 45001 |
| Warranty |
15-year product warranty | 30-year linear power warranty |
