Description
The LONGi LR7-72HVH-635M is an official Hi-MO X10 Explorer (LR7-72HVH 635–650M) photovoltaic module. Rated maximum power at STC is 635 W.
- Official model: LR7-72HVH-635M
- STC: Pmax 635 W; Voc 53.6 V; Isc 15.05 A; Vmp 44.26 V; Imp 14.35 A; efficiency 23.5%
- Official weight 28.5 kg; dimensions 2 382 × 1 134 × 30 mm
- Glass: single glass, 3.2 mm coated tempered glass; 144 (6 × 24) cells; junction box IP68 with three diodes
Figures are from LONGi’s official Hi-MO X10 Explorer (LR7-72HVH 635–650M) datasheet, column LR7-72HVH-635M.
Technical specifications (LR7-72HVH-635M)
| Official model |
LR7-72HVH-635M |
| Family |
Hi-MO X10 Explorer (LR7-72HVH 635–650M) |
| Maximum power (STC) |
635 W |
| Voc / Isc (STC) |
53.6 V / 15.05 A |
| Vmp / Imp (STC) |
44.26 V / 14.35 A |
| Module efficiency (STC) |
23.5% |
| Dimensions (L × W × D) |
2 382 × 1 134 × 30 mm |
| Weight |
28.5 kg |
| Cells / glass / frame |
144 (6 × 24); single glass, 3.2 mm coated tempered glass; anodized aluminium alloy |
| Junction box / cable / connector |
IP68, three diodes; 4 mm²; EVO2A (Staubli) or PV-LR5 (LONGi) |
| Operating temperature |
−40 °C to +85 °C |
Official power tolerance and warranty terms are as stated on the current LONGi datasheet (first-year and annual degradation figures should be taken from that sheet).
Official Datasheet: Official datasheet
This product must be installed by a qualified electrician. All installations must adhere to local wiring regulations and standards.
