Description
The BSLBATT B-LFP12-100S is an official ultra-thin 12.8 V, 100 Ah LiFePO4 flat-pack battery in the lead-acid replacement series, for RV and similar energy-storage use. Official rated energy is 1.28 kWh.
- Official model: B-LFP12-100S; 12.8 V; 100 Ah; 1.28 kWh; 4S1P; 3.2 V / 100 Ah cells
- Maximum charge 100 A; maximum discharge 200 A; pulse 300 A for 5 s
- Official weight approx. 15 kg; dimensions 270 × 600 × 65 mm (W × D × H)
- Natural cooling; voltage range 9.2 V to 14.6 V
Figures are from BSLBATT’s official B-LFP12-100S / B-LFP12-200S datasheet published on bslbatt.com, B-LFP12-100S column.
Technical specifications (B-LFP12-100S)
| Official model |
B-LFP12-100S |
| Battery type |
Ultra-thin LiFePO4 lead-acid replacement |
| Cell / configuration |
3.2 V / 100 Ah; 4S1P |
| Voltage range / rated voltage |
9.2 V to 14.6 V / 12.8 V |
| Rated capacity / energy |
100 Ah / 1.28 kWh |
| Maximum charge / discharge current |
100 A / 200 A |
| Pulse current |
300 A, 5 s |
| Recommended discharge voltage |
11.2 V (the official sheet also prints 13.6 V to 13.8 V on a second row with the same label) |
| Cycle life |
Approx. 4 000 cycles at 25 °C, 0.5C / 0.25C, 80% DoD |
| Short-circuit current |
Approx. 1 200 A, < 10 ms |
| Dimensions (W × D × H) |
270 × 600 × 65 mm |
| Weight |
Approx. 15 kg |
| Internal resistance (fully charged, 25 °C) |
10 mΩ |
| Thermal management |
Natural cooling |
| Operating temperature |
Charge 50 °C as printed on the official 100S column; discharge −20 °C to 65 °C |
| Operating humidity |
60% ± 25% RH |
Warranty: Refer to BSLBATT’s current official warranty terms for this product. A warranty period is not printed on this datasheet.
Official datasheet (PDF): Official datasheet (PDF)
This product must be installed by a qualified electrician. All installations must adhere to local wiring regulations and standards.
