Description
The Deye SUN-100K-PCSL01HP3 is a 100kW three-phase bidirectional power conversion system (PCS) for high-voltage battery storage in commercial and industrial sites. Combined with the Deye STS and MPPT modules it forms a modular ESS that scales to 2.5MW.
- 100kW rated / 110kVA maximum AC power
- 630 – 1000V lithium-ion battery input, 175A charge and discharge
- 98.5% maximum efficiency (97.8% Euro)
- Built-in zero-export and time-of-use control – no separate EMS needed
- Wi-Fi, RS485, CAN and meter interfaces; Deye Cloud monitoring
- IP65 PCS module with intelligent air cooling
Specifications (SUN-100K-PCSL01HP3)
| Battery type |
Lithium-ion |
| Battery voltage range |
630 – 1000V |
| Max. charge / discharge current |
175A / 175A |
| Rated AC power |
100kW |
| Max. AC apparent power |
110kVA |
| Rated AC current |
151.6A / 145A |
| Max. AC current |
166.7A / 159.5A |
| AC voltage |
220/380V, 230/400V (3L+N+PE) |
| Frequency |
50 / 60Hz |
| Power factor |
-1 ~ 1 |
| THDi |
<3% |
| Max. / Euro efficiency |
98.5% / 97.8% |
| Communication |
Wi-Fi, RS485, CAN, Meter |
| Operating temperature |
-25 to +60°C (derating above 45°C) |
| Ingress protection |
IP65 |
| Dimensions (W × H × D) |
543 × 310 × 775mm |
| Weight |
70.35kg |
| Warranty |
5 years (up to 10 years depending on country) |
Official Datasheet: Deye 100kW–2.5MW C&I ESS Solution Datasheet
This product must be installed by a qualified electrician. All installations must adhere to local wiring regulations and standards.
