| Maximum power (Pmax, STC) |
430W |
| Open circuit voltage (Voc) |
39.13V |
| Short circuit current (Isc) |
14.15A |
| Voltage at maximum power (Vmp) |
32.84V |
| Current at maximum power (Imp) |
13.10A |
| Module efficiency |
22.0% |
| Pmax at NOCT |
321W |
| Power output tolerance |
0 to +3% |
| Voc and Isc tolerance |
±3% |
| Temperature coefficients |
Pmax -0.290%/°C | Voc -0.230%/°C | Isc +0.050%/°C |
| Nominal operating cell temperature |
45 ±2°C |
| Operating temperature |
-40°C to +85°C |
| Maximum system voltage |
1500V DC (IEC/UL) |
| Maximum series fuse rating |
25A |
| Protection class | fire rating |
Class II | UL type 1 or 2, IEC Class C |
| Cells |
108 (6 x 18), HPBC cell |
| Glass |
Single glass, 3.2mm coated tempered glass |
| Frame |
Black anodised aluminium alloy |
| Junction box |
IP68 |
| Output cable |
4mm², ±1200mm (length can be customised) |
| Mechanical load |
Front 5400Pa | rear 2400Pa |
| Hail test |
25mm hailstone at 23m/s |
| Dimensions |
1722 x 1134 x 30mm |
| Weight |
20.8kg |
| Packaging |
36 pcs per pallet |
| Degradation |
Under 1.5% in year one, 0.40% per year in years 2-25 |
| Certifications |
IEC 61215, IEC 61730, UL 61730, IEC 62941, ISO 9001, ISO 14001, ISO 45001 |
| Warranty |
15-year product warranty | 25-year linear power warranty |
