Description
The Solar MD SS216 is a 16 kWh low-voltage lithium iron phosphate (LiFePO4) rack-mount battery module. It is designed to combine with Solar MD’s CB racking system (CB35, CB36 and CB39 cabinets) into a scalable battery system. Multiple SS216 modules can be added in a cabinet, and cabinets can be connected in parallel.
- 16 kWh rated capacity per module, 51.2 V nominal
- LiFePO4 (lithium iron phosphate) cells (CATL)
- 8 kW nominal power @ 0.5C
- 157 A maximum charge and discharge current
- Cycle life ≥ 7000 at 25 °C
- CANBUS / RS485 communication
Technical specifications (SS216 module)
Figures in the table are for a single SS216 module, from Solar MD’s official SS216 Low Voltage Cabinets datasheet (April 2025), linked from Solar MD’s product page. Cabinet (CB35 / CB36 / CB39) capacity ranges, rack weights and overall dimensions are in that same datasheet and apply to a populated cabinet, not to this single module listing.
| Official model |
SS216 |
| Battery type |
Lithium iron phosphate (LiFePO4) |
| Cell manufacturer |
CATL |
| Rated capacity |
16 kWh |
| Nominal power @ 0.5C |
8 kW |
| Nominal voltage |
51.2 V |
| Operational voltage |
44.8 – 55.6 Vdc |
| Max. charge / discharge current |
157 A |
| Cycle life @ 25 °C |
≥ 7000 |
| Charging efficiency |
99% |
| Operational temperature |
0 °C to 50 °C |
| Communication |
CANBUS / RS485 |
| Weight per module |
112 kg |
| Dimensions (W × D × H) |
426 × 722 × 230 mm |
| Installation |
Rack-mount module for Solar MD’s CB low-voltage cabinet range (CB35 / CB36 / CB39) |
| Storage duration |
6 months @ 25 °C |
| Safety standard compliance |
CE / EN 55016 / IEC 61000 |
| Cell certificate |
IEC 62619 / UN38.3 / UN3480 / UL 1642 / UL 1973 |
Warranty: Solar MD’s official SS216 datasheet states a 5-year guarantee on product material and workmanship and a 12-year energy output warranty. See Solar MD’s official General Terms and Conditions (new cells).
Official Datasheet: Solar MD SS216 Low Voltage Datasheet (PDF, April 2025)
Official Product Page: Solar MD SS216
This product must be installed by a qualified electrician. All installations must adhere to local wiring regulations and standards.
